The EMC cable entry frame EMC-KEL-DS has been metallized (galvanize coated) to create a conductive surface.
The front cable grommet (KT) is used for strain relief and cable sealing on the cable jacket. The cable shield is contacted over 360° via the rear conductive grommet (EMC-KT).
The EMC-KEL-DS frames match exactly the cut-out dimensions for 24-pin standard industrial connectors. Either a cut-out of 36 mm or 46 mm in height can be chosen depending on the cables being routed.
The contact between the EMC-KEL-DS and the conductive housing wall is realized via the included conductive flat gasket.
It is also possible to integrate threaded bushings. Please ask us about your desired variant. The version with threaded bushings enables the cable entry frame to be screwed onto the housing from the inside out. This protects against vandalism and tampering with the housing from the outside.
| IP rating (EN 60529) | IP54, IP55 |
| Flame class | UL94-HB |
| Operating temperature | -40 C° to 140 C° |
| Material | Polyamide, highly conductive coating |
| Mounting options | Screw type mounting |
| Part No. | 99410 |
| EAN | 4251269322679 |
| Package quantity | 1 |
| Mounting options | Screw type mounting |
| For max. no. of cables | 10 |
| Max. cable diameter | 17 mm |
| Length | 147 mm |
| Width | 58 mm |
| Height | 40 mm |
| Mounting height | 40 mm |
| Cut-out size | 112 × 36 mm |
| No. of screw holes | 4 |
| Diam. of screw holes | 5.8 mm |
| Screw material | Stainless steel (V2A) |
| Suitable for grommets | 10 x EMC-KT small, 10 x KT small |
| Part No. | 99411 |
| EAN | 4251269322686 |
| Package quantity | 1 |
| Mounting options | Screw type mounting |
| For max. no. of cables | 7 |
| Max. cable diameter | 35 mm |
| Length | 147 mm |
| Width | 58 mm |
| Height | 40 mm |
| Mounting height | 40 mm |
| Cut-out size | 112 × 36 mm |
| No. of screw holes | 4 |
| Diam. of screw holes | 5.8 mm |
| Screw material | Stainless steel (V2A) |
| Suitable for grommets | 6 x EMC-KT small, 1 x EMC-KT large |
| Part No. | 99412 |
| EAN | 4251269322693 |
| Package quantity | 1 |
| Mounting options | Screw type mounting |
| For max. no. of cables | 4 |
| Max. cable diameter | 35 mm |
| Length | 147 mm |
| Width | 58 mm |
| Height | 40 mm |
| Mounting height | 40 mm |
| Cut-out size | 112 × 36 mm |
| No. of screw holes | 4 |
| Diam. of screw holes | 5.8 mm |
| Screw material | Stainless steel (V2A) |
| Suitable for grommets | 2 x EMC-KT small, 2 x EMC-KT large |
